Advanced Cell Technology: Utilizes N-type monocrystalline silicon wafers combined with Tunnel Oxide Passivated Contact (TOPCon) technology. This significantly reduces Light Induced Degradation (LID) and Light and Elevated Temperature Induced Degradation (LeTID), enhancing long-term reliability and power generation performance under low-light conditions.
Jinko HOT3.0 Technology: This proprietary technology platform further ensures high module reliability and superior power generation efficiency.
Industry-Leading Power & Efficiency: Under Standard Test Conditions (STC), the module delivers a maximum power output range of 605W to 630W, with a module conversion efficiency of up to 23.3%, maximizing energy yield per unit area.
Exceptional Durability & Warranty: Backed by a 12-year product and workmanship warranty and a 30-year linear power output warranty. It features a first-year degradation rate of only 1%, followed by a low annual linear degradation rate of 0.40%, guaranteeing stable long-term energy production.
Bifacial Energy Gain: Features bifaciality, harnessing reflected light from the ground to generate additional electricity, significantly boosting overall system yield.
Robust & Reliable Design:
Employs Multi-Busbar (MBB) technology to optimize current collection, reduce resistive losses, and enhance resistance to Potential Induced Degradation (PID).
Offers excellent mechanical load resistance with a maximum positive static load of 5400 Pa and a negative static load of 2400 Pa, suitable for harsh environments.
Equipped with an IP68-rated junction box for safe operation in extreme weather.
Optimized Temperature Performance: A maximum power temperature coefficient of -0.29%/°C ensures lower power loss and more stable generation in high-temperature environments.
Dimensions & Weight: The module dimensions are 2382 mm × 1134 mm × 30 mm, weighing approximately 32.4 kg, which facilitates installation and handling.
Global Compliance: Complies with the latest international standards IEC 61215:2021 and IEC 61730:2023. Certified under ISO 9001 (Quality Management), ISO 14001 (Environmental Management), and ISO 45001 (Occupational Health & Safety Management) systems, meeting the entry requirements for major global markets.
Efficient Transportation: Features optimized packaging with pallet dimensions of 2396 mm × 1110 mm × 1251 mm. A 13-meter flatbed truck can load 720 modules, while a 17.5-meter flatbed can load 900 modules, effectively reducing transportation costs.
Broad Application Scope: Wide operating temperature range (-40℃ to +70℃), maximum system voltage of 1500VDC, and maximum series fuse rating of 35A. Its bifacial performance (affected by the bifaciality factor) makes it suitable for diverse applications, including large-scale ground-mounted power plants, commercial & industrial rooftops, and projects in complex terrains.
In Conclusion
The JinkoSolar JKM605-630N-66HL4M-BDV-F3-CN N-type TOPCon module combines high efficiency, high reliability, excellent low-light performance, significant bifacial gain, and long-term stable power output. Its robust mechanical strength, global certifications, and optimized logistics design make it an ideal choice for solar power plant projects seeking high investment returns and long-term dependable operation, delivering exceptional clean energy value to customers.
